Increase uptime of your process critical equipment.
Transponder
Communicates with sensors and securely transfers data to the cloud.
Communication
16-bit MCU
Protocol 802.11 b/g/n WiFi 2.4 GHz
WPA2 with AES encryption
Bluetooth low energy 2.4 GHz (Customized Protocol)
Physical Dimensions
Height: 16” / 40.6 cm
Width: 7” / 17.8 cm
Depth: 3.75” / 9.5 cm
Weight: 3.4 lbs / 1.55 kg
Mechanical Specifications
Vibration testing to UN DOT 38.3
Ruggedized enclosures
Corrosion resistant
RoHS compliant
Power requirement 24V DC, < 10W
Sensors
Tri-axial vibration and temperature sensors.
Sensor Data
Tri-axial accelerometer - frequency response up to 8kHz (xy), 5.1kHz (z) - measurement range up to 20 G - 16 bit resolution
Temperature sensor - accuracy of +/- 1°C
Physical Dimensions
Height: 5” / 12.7 cm
Largest diameter: 2” / 5.1 cm
Weight: 0.33 lbs / 0.15 kg
Mounting Provisions
Magnetic mounts
Epoxy or threaded studs
¼-28 UNF tapped hole
Mechanical Specifications
Ruggedized enclosures
Corrosion resistant
Stainless steel base
RoHS compliant
Temperature operation to -20C to +60C (-4F to +140F)
Cloud-based software program
Delivers actionable data customized to your specifications and tailored alerts via SMS, email or phone.
Dashboard
Easy to understand temperature and vibration charts
Peak overall velocity graphs for vibration analysis
Isolate X, Y, or Z Axis for vibration analysis
8192 samples with each vibration data point
Toggle between celsius and Fahrenheit
Easy to recognize notification features designed to reduce alert fatigue
Variable sampling frequencies of 256 Hz, 512 Hz, 1024 Hz, 2048 Hz, 4096 Hz, and 8192 Hz
Customization
Easily map your equipment with your terminology
Time domain waveforms available
Spectral waveforms available (FFT)
Create notification groups and escalation groups (SMS or Email)
Monthly Live Facility & Asset Update With a VERO Vibration Expert Helps With:
Analyzation & Recommendation for all
Asset and Sensor Warnings
Threshold Settings and Modification
Vibration Best Practices
No batteries to replace
Expert vibration analysis
Easy professional installation
Customized scorecard and analytics
Lifetime warranty and automatic upgrades
Subscription pricing = no CapEx
Our Solution Architects visit your site and evaluate your needs.
We’ll design a custom VERO solution for your equipment and facility.
Once approved we’ll plan and schedule installation.
